Dannysound - Timbre
Product information "Dannysound - Timbre"
The wave folder adds extra harmonics to input signals that have low harmonic content to creating rich and interesting timbres.
Typical input sources to use would be Sine and Triangle waves but you are welcome to try other sources as well!
The Dannysound Timbre adds an extra input to the Buchla design to allow 2 oscillators to drive the wave-folder simultaneously –
this dramatically increases the range of possible tones that can be generated and allows the folder to go wild!
Buchla 259 inspired waveshaper, the perfect module to put in-between your Dannysound Cali and EN129 oscillators!
Features:
• Osc1 / Osc2 Mix – Adjusts mix between oscillator 1 and 2 inputs, also acts as an attenuator if only one of the inputs is used.
• Timbre Control – Adjusts the overall wave fold amount.
• Timbre CV – Bipolar (attenuverter) controls the Timbre CV input.
• Symmetry – Adds an offset to the input so the top half of the wave starts folding earlier.
• Blend – Mixes between the clean and effected sound.
DIY-Kit-Type:
THT-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. Only trough-hole parts to solder. Make sure to check the build guide before you buy. For build guide, more info, videos etc. please check the buttons below.
| Current draw +12 V [mA]: | 46 |
|---|---|
| Current draw -12 V [mA]: | 48 |
| DIY Level: | Advanced |
| Depth [mm]: | 48 |
| Width [HP]: | 6 |
| Format: | 3U |
| Panel / Color: | Silver Alu |
