Introducing ADDAC’s Cable Tester, a desktop utility that provides a reliable means to test the integrity of both mono jacks and ribbon cables, ensuring that every connection is secure and electrically sound.Individual Wire Testing - Featuring the ability to test each wire within the ribbon cables independently with dedicated LEDs for every wire, providing a clear visual indication of the status of each connection, wires are also tested against their neighbouring wires to detect shorts.BUSBOARD MONITORThe busboard monitor leds allows the user to check the state of the busboard power lines as well as the special CV/Gate functions. If the busboard has no +5v supply the led will be off likewise for the CV/Gate functions if not in use.This is a desktop device, we provide a long power cable so that it can still be plugged into your rack.As a safety precaution only power this board when you need to test a cable. Leaving it ON at all times can lead to unintended problematic misuses which, in a worst case scenario, can shorten your Eurorack PSU,! WARNING !DO NOT POWER MODULES FROM THE TEST SOCKETS!!Compatible with all ADDAC System ribbon cables (power, expansions and interconnectivity: 112, 213, 807).Also compatible with any standard Eurorack power ribbon cable (2x5 to 2x8 or 2x8 to 2x8).! WARNING !NOT ALL MANUFACTURERS FOLLOW THESE STANDARDS!ALLWAYS NOTICE THE ORIENTATION OF THE HEADERS IF YOUR CABLE DO NOT FOLLOW THE STANDARD THEN MOST PROBABLY IS NOT COMPATIBLE.DIY-Kit-Type:SMD-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. All SMD parts are pre-soldered, only trough-hole parts to solder. For build guide, more info, videos etc. please check the buttons below.
16n AtoVproject Rework is discontinued. The 16n AtoVproject Rework is aimed at solving a problem very specific to modular synthesis. As a patch is getting more and more complex a forest of cables has grown over your system before you know it. This module allows you to take the control from the modular into a very ergonomic controller that integrates perfectly into a modern studio.The 16n AtoVproject Rework is a controller sending CV, I2C, MIDI jack, USB MIDI (compatible PC, Mac, iPad etc...), making it the absolute ultimate controller for any of your hardware and software all in one!Even better this controller can either be used as a Eurorack module or as a standalone unit using the beautiful aluminum enclosure.In 2019, the Berlin Modular community showed interest in building the 16n Faderbank. As one of the Berlin Modular community organizers, I decided to make a redesign of the 16n faderbank following the suggestions and desires of our members. The 16n AtoVproject Rework is the result.Features:• 16 high-end Alps faders• Eurorack compatible (50hp) and standalone enclosure (for use in or out of the rack)• Selectable 0-5V or 0-10V CV output range (independent setting for each fader)• High stability power conditioning for high stability analog outputs• Soft MIDI thru. MIDI data sent to the 16n through USB is echoed to the MIDI jack (Since firmware v2.1.0)• Utility connector on the back of the unit to simplify the use of i2c with modules like the ER301DIY-Kit-Type:SMD-Kit-2. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. It includes SMD and through-hole parts! For build guide, more info, videos etc. please check the buttons below.
16n AtoVproject Rework is discontinued. The 16n AtoVproject Rework is aimed at solving a problem very specific to modular synthesis. As a patch is getting more and more complex a forest of cables has grown over your system before you know it. This module allows you to take the control from the modular into a very ergonomic controller that integrates perfectly into a modern studio.The 16n AtoVproject Rework is a controller sending CV, I2C, MIDI jack, USB MIDI (compatible PC, Mac, iPad etc...), making it the absolute ultimate controller for any of your hardware and software all in one!Even better this controller can either be used as a Eurorack module or as a standalone unit using the beautiful aluminum enclosure.In 2019, the Berlin Modular community showed interest in building the 16n Faderbank. As one of the Berlin Modular community organizers, I decided to make a redesign of the 16n faderbank following the suggestions and desires of our members. The 16n AtoVproject Rework is the result.Features:• 16 high-end Alps faders• Eurorack compatible (50hp) and standalone enclosure (for use in or out of the rack)• Selectable 0-5V or 0-10V CV output range (independent setting for each fader)• High stability power conditioning for high stability analog outputs• Soft MIDI thru. MIDI data sent to the 16n through USB is echoed to the MIDI jack (Since firmware v2.1.0)• Utility connector on the back of the unit to simplify the use of i2c with modules like the ER301DIY-Kit-Type:SMD-Kit-2. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. It includes SMD and through-hole parts! For build guide, more info, videos etc. please check the buttons below.
Looping is one of the fastest and most intuitive ways of music-making. It's always been great for improv and invention, but why not try it with MIDI messages this time?The Bastl Midilooper is an experimental device that will help you do just that. It listens to control information about notes, dynamics, and other parameters, and it loops them in a way an audio looper would process pieces of audio. Since the MIDI loops remain in the control domain, many other processes can happen simultaneously on top of them - so you can explore timbre modulation, envelope adjustments, and way more.We designed the controls of the Midilooper to be easy to access so that the device comes in handy and enhances your music-making flow. Your fresh ideas are just a few button presses away: “[The Midilooper is] highly recommended if you’re trying to simplify your workflow and/or get away from menu-diving outside of the computer,” says a recent review in The Waveform Magazine, and we couldn’t agree more.Features:• 3 independent voices (each has MIDI channel assigned)• overdub/overwrite• transpose mode• octave transpose• quantize, velocity lock, shuffle, humanize• odd looplengths, time stretch• mute, clear, erase• one MIDI Input and two MIDI Outputs• clock input (accepts analog clock or TRS MIDI Clock)• analog reset input• metronome output• CV input connectivity (transpose, velocity, re-trigger)• pedal control (record, clear, voice selection)• USB powered• adjustable divider/multiplier for the analog clock• dimensions: 125mm x 80mm x 35 mm
Experimental synth voice focused on ambient pads and drone-like soundscapes.Features:• Stereo External input with selectable gain.• 5-second looper Records either the stereo input or the module’s output• Sine oscillator• Supersaw oscillator• Wavetable oscillator that uses the Looper buffer• Multimode filter: low-pass, band-pass, high-pass, and comb filter.• 3-band resonator• 2-tap echo• Reverb with macro control for size, filtering, and direction.• CV Control with attenuators on most parameters.• Various types of self-modulation with configurable routing and control over level and speed.• External synchronization via sync input.• Powerful randomizer with four different targets, three levels of intensity and undo/redo.• Knobs catch behavior functionality for re-coupling parameters’ positions.DIY-Kit-Type:SMD-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. All SMD parts are pre-soldered, only trough-hole parts to solder. For build guide, more info, videos etc. please check the buttons below.
Oneiroi is a full-stereo synthesizer crafted for dreamlike soundscapes, immersive textures, and cinematic atmospheres. At its core lies a rich combination of synthesis engines and creative sound processing: a sine wave oscillator, a versatile wavetable/supersaw voice, and a playful looper capable of recording external input or internal output with “sound-on-sound” layering. These elements flow into a powerful effects section featuring a multimode filter, resonator, stereo delay, and lush reverb—ideal for generating hypnotic drones, evolving pads, and experimental sonic landscapes.Modulation possibilities within Oneiroi are highly flexible, thanks to complex internal routing and a powerful randomizer that generates instant patches at the press of a button. With four distinct targets, three levels of intensity, and dual switch-controlled behavior, it lets you dial in anything from subtle variation to wild, unpredictable textures—complete with undo/redo to capture the perfect moment.The built-in 5-second looper not only captures audio but also feeds directly into the wavetable oscillator, enriching your sound palette with evolving textures. Whether you're layering field recordings, sampling your own tones, or sculpting ambient washes from scratch, Oneiroi encourages spontaneous creativity and deep modulation.This version includes a 4ms Pod 42 HP powered case, transforming Oneiroi into a self-contained, portable stereo powerhouse—perfect for live performance, studio exploration, and ambient sessions on the go.Features:• Stereo External input with selectable gain.• 5-second looper Records either the stereo input or the module’s output• Sine oscillator• Supersaw oscillator• Wavetable oscillator that uses the Looper buffer• Multimode filter: low-pass, band-pass, high-pass, and comb filter.• 3-band resonator• 2-tap echo• Reverb with macro control for size, filtering, and direction.• CV Control with attenuators on most parameters.• Various types of self-modulation with configurable routing and control over level and speed.• External synchronization via sync input.• Powerful randomizer with four different targets, three levels of intensity and undo/redo.• Knobs catch behavior functionality for re-coupling parameters’ positions.DIY-Kit-Type:SMD-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. All SMD parts are pre-soldered, only trough-hole parts to solder. For build guide, more info, videos etc. please check the buttons below.
When you start out into synths and synthesis, Bullfrog is worth every cent for the synth itself and the provided brilliant learning materials. You'll go home with lots of knowledge!Created by Erica Synths & Richie Hawtin, Bullfrog is an educational electronic music instrument designed to captivate and inspire both youth and professionals alike. Bullfrog invites you to unlock musicality while combining the thrill of electronic music production with a comprehensive learning experience.Bullfrog is a classical subtractive synthesizer - it consists of several “modules” for sound generation - VCO, NOISE GENERATOR - and treatment - VCF, VCA/DELAY, as well as “modules” that generate control and modulation signals to control them - ENVELOPE GENERATORS and SAMPLE & HOLD. The Bullfrog will not make the sound on its own unless it is patched - using eurorack patch cables to interconnect the “modules” or by inserting voice cards that create internal connections between the “modules” in a specific way and add extra functionality, like sampler/looper, sequencer, groovebox, etc. This approach better helps to understand the functionality of a subtractive synthesizer and the principles of sound design with instruments like these.What’s included:• BULLFROG synthesizer• Universal 12VDC wall wart adapter• User manual• 10 patch cables• 3 pre-patched voice cards: Sequencer, Acid Bassline, Sampler Looper• 3 DIY voice cardsIn order to provide a well-rounded understanding of the functionality of this synthesizer and sound synthesis in general, a comprehensive user manual is created to accompany the learning process. Use the buttons below to get to the project pages.Features:• Fully analogue design• Highly accurate voltage controlled oscillator (VCO) that tracks great over 8 octaves• Manually adjustable and voltage controlled waveshapes - sine-shark fin and pulse wave with pulse width modulation (PWM)• Zener diode-based noise generator• Resonant lowpass voltage controlled filter (VCF)• Voltage controlled amplifier (VCA) with adjustable offset• Delay effect with adjustable delay time and feedback amount• Two looping attack-sustain-release envelope generators (EG)• Sample & Hold circuit with an individual clock• Manual gate button• Voicecard slot• Built in speaker• DIN5 MIDI input• USB connector• Dimensions: 40 x 385 x 210 mm• Weight: 1.8 kg
This is the Full Kit with a wide assortment of essential components (resistors, capacitors, ICs, transistors) so you can start building right away.Get started in circuit design with MKI x ES Labor. Developed in collaboration with Dr. Shalom D. Ruben teaching professor for engineering at the University of Colorado Labor is a fully-featured circuit design playground and a powerful electronics learning tool all in one. Created with the aim of serving as a universal learning tool for electronics engineering Labor enables users to delve into various aspects of electronics design from fundamental concepts to advanced techniques. Whether you're a beginner exploring the basics or an experienced engineer honing your skills Labor provides a versatile platform for experimentation and learning. Create your own filters oscillators envelopes sequencers – and whatever else you can come up with. Or use it to learn the basics by following along with our series of educational DIY kits.Features:• a built in dual power supply producing eurorack-compatible voltages, with built-in over current protection for safe experimenting• a modular interfacing section with 16 slots for potentiometers, jacks & switches• a pulse/triangle/sine oscillator (audio & LFO range)• a multi mode envelope generator controlled by a premium push button• a buffered variable control voltage source• an output amplifier with variable gain• a dedicated headphone output and a line-level output for recording, processing and analyzing the signal• an expansion slot for installing specialized prototyping tools• a protective lid to cover a breadboard.EDU DIY Labor Full Kit includes:• LABOR• Power Supply Unit• jumper cables• array of interfacing elements like potentiometers, jack sockets, switches• commonly used components (resistors, capacitors, chips, transistors) to start building circuits straight awayNB! LABOR is a testing ground for experiments with electronic circuits and we as a manufacturer cannot by any means diagnose any issues with circuits designed on the LABOR board. We will only respond to support tickets regarding obvious malfunctions of the factory-soldered circuits on the main LABOR board. For other cases of malfunction – please consult other LABOR users/ experienced DIY kit builders on online forums, such as this one. Keep experimenting – keep trying!DIY-Kit-Type:SMD-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. All SMD parts are pre-soldered, only trough-hole parts to solder. For build guide, more info, videos etc. please check the buttons below.
Another non-musical object, but fun. With this DIY kit you can possibly convince your kids and partner, that it’s a ok to spend all your cash in your hobby ;-) With this christmas ball, featuring pulsating lights you can contribute something to your family’s christmas tree. This is a very easy DIY project, maybe a first one for your kids. 3 LEDs, a switch and a battery holder.DIY-Kit-Type:SMD-Kit-2. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. It includes SMD and through-hole parts! For build guide, more info, videos etc. please check the buttons below.
This is the DIY version of this unit.Pathways is a modular matrix mixer designed for feedback manipulation, creative routing, weird synthesis… and many other things.Based around sixteen analog VCAs it can be the central hub of many different setups and a bridge between desktop gear and eurorack systems.Features:• 4x 1/4″ inputs with gain / drive control, 4x 1/4″ outputs• Each of the 16 matrix intersections can be controlled manually or via CV, a dedicated LED gives visual feedback of the channel volume• An envelope follower is normalled to input four, the signal then gets fed through a clock divider with three cascaded outputs. Willingly, an external signal can be inserted into the divider• Two voltage controlled LFOs can modulate any parameter and create dynamic feedbacks, asymmetrical panning, tempo-related fx send/returns• If patched into itself, each channel can self oscillate so it can be used as a polyphonic cv-controllable drone synthesizer• full eurorack compatibility, each parameter has its own 1/8″ input jackDIY-Kit-Type:SMD-Kit-1. This is a Do-It-Yourself kit, not an assembled unit. The kit includes all parts to build the unit. All SMD parts are pre-soldered, only trough-hole parts to solder. For build guide, more info, videos etc. please check the buttons below.
This is the DIY version of this unit.Solid Felt is a stereo multimode analog filter in desktop format.Its name comes from the etymology of the words “stereo” and “filter”.From subtle timbral variation to an all-encompassing sonic treatment, Solid Felt can be used in multiple ways to embellish or vandalize your sound bouquet:As two independent mono filtersto give a stereo treatment to a mono signalto filter a stereo signal at the same cutoff frequency on the L and R channelsAs a mono 24dB/oct filter (placing the two filters in series)To synthesize sounds, via external feedback patchingTo extrapolate a CV signal from your audio input and use it to control any of its parameter or external gearAs a stereo overdrive effectTo bring line level signals to Eurorack levelFeatures:• 2x Analog multimode analog filters• 2x 1/4″ jack high impedance inputs• 2x 1/4″ jack low impedance outputs• 8x 1/8″ jack eurorack compatible CV inputs• 8x 1/8″ jack eurorack compatible CV outputs• Input gain control to amplify incoming signals up to fuzzy territory• mode control to select between lowpass, bandpass and highpass filter response (CV controllable)• an envelope follower (normalled to input A) which is fed into a three stage clock divider• a voltage controlled LFO with waveform blend control and two outputs 180° out of phase• a voltage controlled LFO with rising and falling sawtooth outputsDIY-Kit-Type:SMD-Kit-1. This is a Do-It-Yourself kit, not an assembled unit. The kit includes all parts to build the unit. All SMD parts are pre-soldered, only trough-hole parts to solder. For build guide, more info, videos etc. please check the buttons below.
Hidden beyond the realm of sight and touch, lies a world of electromagnetic signals, hidden to you. This Sensory Enhancement Device™ will allow you to finally achieve the enlightenment of electromagnetic signals you seek. No mere bit-sniffer attached to a jack, this device is an iteration on the Herzlich SEE ALL, but upgraded with 1/4" jacks, hand friendly sizing and stereo pickups.Finally, the strange world of electromagnetism can be heard by human ears in stereo. Move through the world, listening to the harmonies of electric and electronic signals that surround us, and capture them in pristine stereo for later.This is a passive module. It requires amplification to hear the true splendour of the hidden world. Suitable for experimental musicians and field recording enthusiasts alike. A field recorder with a bit of amplification on tap is recommended.Features:• Listen to the secret world of electromagnetic signals - in stereo!• Passive design - never run out of batteries again• Body contacts allow you to become a fleshy antenna• Record an entire experimental noise album in an afternoonDIY-Kit-Type:THT-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. Only trough-hole parts to solder. Make sure to check the build guide before you buy. For build guide, more info, videos etc. please check the buttons below.
HEX cor is a digital polyphonic synthesizer with a capacitive keyboard, potentiometers for signal modulation and an adaptable looper that through its unusual shape explores new ways of interaction and sound synthesis.Features:• Capacitive pads• Recording button• Octave• Waveform• Decay• Loop speed• Loop length• Sync switch• Header pins• 3,5 mm headphone jack output• USB C power portDIY-Kit-Type:SMD-Kit-2. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. It includes SMD and through-hole parts! For build guide, more info, videos etc. please check the buttons below.
Hex lag is a digital sound processing instrument with signal modulating potentiometers and an interactive tactile surface for direct sound control. It digitally simulates analogue bucket brigade delay chips (typical of chorus, flanger and karplus-strong), but also enables pitch-shifting, downsampling, etc.Features:• Touch pads• Gain• Rate• Spread• Feed• Push button• Header pins• 3,5 mm input• 3,5 mm output• USB C power portDIY-Kit-Type:SMD-Kit-2. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. It includes SMD and through-hole parts! For build guide, more info, videos etc. please check the buttons below.
HEX row is an analogue dual resonant filter with versatile routing capabilities, sidechain/envelope follower and mischievous character, stemming from (mis)use of transistors as variable resistors in the signal route.There are two channels, each controlled by three potentiometers: GAIN (2), RES (3), FREQ (4) and sidechained by CENTER (5). Both channels have the same topology. Inputs •| and |• are fed into each channel’s gain stage and then passed to their filters. The input signal level can be adjusted by setting the GAIN which can either attenuate or amplify a signal x20. Note that the amplification affects the filter’s behaviour—high GAIN disrupts self-oscillation, conjuring PLL-esque harmonics and other sound design artefacts. FREQ and RES are used to manipulate individual filter’s cutoff frequency and resonance. Each channel has a side-mounted switch (6) for selecting low-pass or band-pass filtering. Touch the golden touch pads (1) to manually route the flow of audio and control voltages.SIDECHAIN – Left channel’s (•I, •O) post-gain signal is filtered and fed into an envelope follower. Envelopes polarity and amplitude are adjusted by using CENTER. The adjusted envelope is then mixed in the right(|•, O•) channel’s FREQ parameter. Left half of the CENTER causes the filter to “duck” and the right half produces a gating response. In the middle position, the sidechain effect is inactive.TOPOLOGIESFEEDBACK – Connect the •O and I• sockets with a jack cable and use O• as the main output. Leave •I unconnected as it’s normalised to O• by default.Alternatively, using stereo cables and a headphone splitter adapter enables the use of •O as output with dramatic stereo field dynamics.SERIAL – Connect the audio source to I• and use the •O as output.Input signals are processed through subsequent channels as •I is normalised to O•. This mode enables the so-called twin peak and auto-filtering.PARALLEL – Connect a stereo audio source into •I or two mono sources to •I and I•.Left and right signals are split into separate channels, processed and output as stereo signal via •O or as mono on both outputs.You will need a soldering iron, solder, pliers, tweezers and some patience. Before you begin the process, make sure you are working on a clean, well-lit surface. Be careful with the components, some of them are very small—take them out of the packaging one at a time, when needed. Most of the tiny SMD components are marked with numbers that match the numbers printed on the PCB. If you are new to soldering (SMD), we recommend watching some online tutorials beforehand. For the assembly video, visit our website. In any case, take it slow, go step by step and enjoy the process of building your HEX. It’s like a puzzle that you can use and play with afterwards. Oh, and if you have any questions, do not hesitate to contact us. Have fun!COMPONENTS1. 4,7uF capacitor / 5x2. 10uF capacitor / 2x3. Header pins / 1x4. 3.5mm jack / 4x5. Potentiometers + knobs / 7x6. Nuts + bolts / 5x7. PCB + wooden base / 1xDIY-Kit-Type:SMD-Kit-2. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. It includes SMD and through-hole parts! For build guide, more info, videos etc. please check the buttons below.
This is the new 2025 Contact Microphone version - better than ever. This is the 3,5mm (1/8") jack connector version. With a contact microphone, any surface or object becomes a canvas for sonic exploration. Unlike traditional recording methods that capture sound waves traveling through air, contact microphones pick up vibrations directly from materials — allowing you to "listen" to objects, plants, or even soil from the inside out. This unique perspective unlocks a world of intriguing and sometimes abstract sounds, making it an essential tool for experimental recording and sound design. The 2025 edition of LeafAudio’s popular contact microphone has been completely re-engineered for maximum flexibility and features full electrical shielding for optimal performance.This upgraded model comes in a set with a durable neoprene zip-bag, ensuring safe transport while providing space for all included accessories. Thanks to its universal clamp mechanism and strong rubber bands, it can be mounted on almost any surface. Additionally, the newly developed probe mechanism — created in collaboration with sound designer Robert Dudzic — lets you capture sounds even from inside objects, soil, and more, expanding the creative possibilities even further.Equipped with a high-quality 2m (6.5ft) SC-Onyx Tynee cable by Sommer Cable, the microphone is available in two versions: one with a 3.5mm (1/8") Amphenol connector and another with a 6.3mm (1/4") Hicon connector. Includes:• Contact microphone• Neoprene zip-bag• Universal holder• Probe mechanism• 2 rubber bands• Allen key
This is the new 2025 Contact Microphone version - better than ever. This is the 6,3mm (1/4") jack connector version. With a contact microphone, any surface or object becomes a canvas for sonic exploration. Unlike traditional recording methods that capture sound waves traveling through air, contact microphones pick up vibrations directly from materials — allowing you to "listen" to objects, plants, or even soil from the inside out. This unique perspective unlocks a world of intriguing and sometimes abstract sounds, making it an essential tool for experimental recording and sound design. The 2025 edition of LeafAudio’s popular contact microphone has been completely re-engineered for maximum flexibility and features full electrical shielding for optimal performance.This upgraded model comes in a set with a durable neoprene zip-bag, ensuring safe transport while providing space for all included accessories. Thanks to its universal clamp mechanism and strong rubber bands, it can be mounted on almost any surface. Additionally, the newly developed probe mechanism — created in collaboration with sound designer Robert Dudzic — lets you capture sounds even from inside objects, soil, and more, expanding the creative possibilities even further.Equipped with a high-quality 2m (6.5ft) SC-Onyx Tynee cable by Sommer Cable, the microphone is available in two versions: one with a 3.5mm (1/8") Amphenol connector and another with a 6.3mm (1/4") Hicon connector. Includes:• Contact Microphone• Neoprene zip-bag• Universal holder• Probe mechanism• 2 rubber bands• Allen key
Field Amp is LeafAudio's solution for the world of body sound transmission: recording the world with contact microphones. It provides high-gain, noise-free amplification and impedance conversion to ensure the best possible sound quality from your contact mics.After releasing our Microphonic Soundbox, we quickly realized we’d hit a sweet spot. Many sound designers praised its clean, noise-free amplification - even if they didn’t need the Soundbox itself. So we listened and created a standalone solution: the Field Amp. If you want the Soundbox amp without the box, the Field Amp is your new best friend. Perfect for studio work, field recording, sound installations, and creative sound design of all kinds.Quality amplification & power management circuitry. No noise or beeping can be heard or seen in the spectrum, not even above the hearing range, which would come into focus later during sound manipulation processes. You can record with high sampling rates, transpose the audio by a lot and enjoy your pure sound. Just the clear, pristine audio you want to capture with your contact microphones.Optimised for travelling. The small unit is fully portable, light, offers many mounting possibilities. A professional case is included, which also can carry your contact mics, batteries and cables.Body sound transmission vs. airborne sound. We’re used to hearing the world the way our ears do—through air. Sound travels through the air before reaching our eardrums or a microphone. But with contact microphones, you change that perspective. Instead of hearing the surface of materials, you hear from within them. This shift opens up a powerful trick for sound design. It reveals a hidden world of textures and tones that are normally out of reach. Give it a try—there’s an entire universe of sound waiting to be discovered.Field Amp is optimised for Hi-Z signals of contact microphones. It also acts as an impedance converter with a powerful output signal. No loss of signal quality when you keep the wiring short between microphones and the input. The output is a strong signal and you don't have to worry about a few meters of cable.We recommend using the shielded contact microphones by LeafAudio. Generally you can try contact mics with our pre-amp, hydrophones, or guitar pickups. We offer separate adapters for both input and output to ensure compatibility with all your devices.Features:• Low-Noise pre-amp for contact mics, geophones etc.• Case included• 9V DC power supply or battery• USB-C to barrel connector adapter cable included• Up to ~50x adjustable gain• 1 mono input• 2 mono outputs (one -12 dB)• All connections 3.5 mm (1/8") mono jack• Input impedance: 3,3M Ohm• Output impedance: 1k Ohm• 12 x 12 x 3.4 cm• 410 g (incl. case & USB-C to barrel cable)• 1/4"-UNC mount on top and bottom for camera tripods etc.
Microphonic Playground is the newest addition in our series of sound design instruments. Like its bigger sister, the Microphonic Soundbox, it's a playground for sonic exploration of any kind. It can also be your inexpensive entry into the Soundbox world before you possibly upgrade later.It works through body sound transmission on basis of a contact microphone. In comparison to airborne sound transmission (via a microphone), all sounds created on the box can be listened to in a very intimate and direct way. Imagine it like listening to the materials from the inside, very much in an ASMR way.The difference to the Microphonic Soundbox are two things:1) It is passive, has no active amplification and needs no power supply.2) It's an open playground with no audio sources or objects built into it, so you are free to attach everything to it what you can imagine.To get you started with ideas we now offer a variety of add-ons, that can be used with both the Microphonic Soundbox and the Microphonic Playground.The unit has an audio input and an output. Its audio output can be amplified by the external input of a Microphonic Soundbox and therefore act as an extension. Or it can be amplified by any pre-amplifier, mixing desk or audio interface. Multiple Playgrounds can be cascaded in series. Play it on its own, or extend your Microphonic Soundbox with one or two Playgrounds and some of the new add-ons.You're free to use it as a platform for sonic experimentation or just convert it into a Bass Kalimba, for example, and leave it that way. Please choose your own way to play with it and let your imagination and creativity guide you.Features:• built in contact microphone• passive, no power supply needed• many mounting possibilities for add-ons through five threaded M3 strips• universal wooden object holder on the side• four M3 thumb screws included• 1 audio input, 1 audio output• multiple units can be linked• soft rubber feet• 162 mm x 147 mm x 60 mm (w/d/h)• 0,244 kg
Microphonic Soundbox mk2 is a versatile sound design instrument and features active battery powered low noise pre-amps. This is the flagship of the Microphonic Soundbox cosmos and features the most possibilities for sonic exploration on the basis of body sound transmission.Standalone it's already fun, but its whole potential is unveiled when it's being processed in realtime by live-sampling, loopers and effects. Possibilities are endless and thousands of sound designers and musicians use it in their creative work process.We recommend to additionally buy the violin bow and rosin for being able to play it properly.Soundbox History: Manuel from LeafAudio created this instrument in the late nineties and used it on lots of his Xabec albums (https://xabec.bandcamp.com), in live shows and sound design work. Before we made it public 2017, it had a 20 year long and very personal history.Features:• Two channels with internal contact microphones• Battery powered low noise pre-amps (~100x / ~40dB Gain)• Two outputs: mixed mono or channels separated• Channel one can act as pre-amp for external input• Multifunctional holder, based on M3 threaded strips (left side & under Kalimba)• Removable Kalimba• Soundbox is a hub for external contact mics: use channel 1 as pre-amp on out 1 while play the actual Soundbox on out 2• Output features an attenuator switch• Power management switches the LED from blue to red when battery goes under 7 volt• Soft grip rubber feet for acoustic decoupling• Removable metal rods which come in a plastic tube which is great for transport
€253.00*
