AF Labs - MI Edges (PCB)
Product number:
100832
Product information "AF Labs - MI Edges (PCB)"
Features:
3 Square/pulse generators
• Aliasing-free digital synthesis, based on a 4 MHz digital timer.
• 5 preset duty cycles settings, from 50% to 95%, or CV-controlled PWM.
1 Noise and triangle generator
• 48kHz, 12-bit DAC without reconstruction filter for a raw sound.
• Triangle, bitcrushed sine, steppy NES triangle or various flavours of LSFR noise.
Advanced features
• Optional semitone quantizer on the pitch CV input.
• Per-channel mini step sequencer (8 steps) – perfect for creating rapid fire arpeggios. When the sequencer is active, the GATE input works instead as a CLOCK input.
DIY-Kit-Type:
PCB only Kit. This is a do-it-yourself PCB kit, no parts or Panel are supplied, you will need to source them yourself.
3 Square/pulse generators
• Aliasing-free digital synthesis, based on a 4 MHz digital timer.
• 5 preset duty cycles settings, from 50% to 95%, or CV-controlled PWM.
1 Noise and triangle generator
• 48kHz, 12-bit DAC without reconstruction filter for a raw sound.
• Triangle, bitcrushed sine, steppy NES triangle or various flavours of LSFR noise.
Advanced features
• Optional semitone quantizer on the pitch CV input.
• Per-channel mini step sequencer (8 steps) – perfect for creating rapid fire arpeggios. When the sequencer is active, the GATE input works instead as a CLOCK input.
DIY-Kit-Type:
PCB only Kit. This is a do-it-yourself PCB kit, no parts or Panel are supplied, you will need to source them yourself.
| Current draw +12 V [mA]: | 20 |
|---|---|
| Current draw -12 V [mA]: | 25 |
| DIY Level: | Advanced |
| Depth [mm]: | 25 |
| Width [HP]: | 20 |
| Format: | 3U |
