North Coast Synthesis - MSK 011 Transistor Mixer
Product information "North Coast Synthesis - MSK 011 Transistor Mixer"
Suitable for both audio and control voltages, with bonus features that don't compromise the minimalist philosophy: positive and negative offset; simultaneous DC- and AC-coupled outputs; maximum gain a little over unity for when you need that extra push over the cliff. It can also function as a transistor distortion effect, by offsetting the signal until it clips and then using the AC-coupled output.
Features:
• High-quality potentiometers with bushings fastened to the panel for wobble-free operation; conductive plastic for smooth feel
• All-new design, not a clone or imitation of anything else
• Classic discrete-transistor design style; DIY kit ships with silicon 2N5088 transistors for a clean modern sound, easily modifiable to use other recent or "vintage" types
• No ICs!
• Through-hole for easy hand construction and maintenance
• No compromises on build quality: real aluminum panel, not PCB material, with colour printing; nickel and gold plating on the circuit board; film output coupling capacitor; close-tolerance metal film fixed resistors.
• Fully open design - no lock-in
DIY-Kit-Type:
THT-Kit-1. This is a Do-It-Yourself kit, not an assembled module. The kit includes all parts to build the module. Only trough-hole parts to solder. Make sure to check the build guide before you buy. For build guide, more info, videos etc. please check the buttons below.
| Current draw +12 V [mA]: | 9 |
|---|---|
| Current draw -12 V [mA]: | 14 |
| DIY Level: | Medium |
| Depth [mm]: | 34 |
| Width [HP]: | 6 |
| Format: | 3U |
| Panel / Color: | Silver Alu |
Matthew Skala is the founder of North Coast Synthesis Ltd. He began exploring hobby electronics in the 1980s, spending time in amateur radio and even completing one of the classic NRI electronics correspondence courses advertised in magazines before the Internet era and the rise of digital computing.
He went on to study computer science, earning a PhD from the University of Waterloo with a specialization in high-dimensional geometry and its applications in areas such as security, database search, and computational linguistics. Over the next 15 years, he worked in academic research and teaching at universities in Canada and Denmark.
In 2017, Matthew left academia to establish his own company in Toronto. Through North Coast Synthesis, he brings the craft of handmade electronics to Eurorack modular synthesizers. His designs are aimed at serious hobbyists and DIY enthusiasts, with a focus on top-quality components, thorough and open technical documentation, and long-term maintainability.
