Bus Cable - 16 to 16 20cm

Please read this safety guide before installation or use.

Intended Use
• Audio cables are designed solely for the transmission of audio signals and should be used according to their technical specifications.
• Use outside the recommended applications (e.g., for electrical loads or non-audio signals) may result in damage to equipment or injury.

Installation and Use

Connection and Disconnection:
• Do not pull the cable by its wire; always pull it by the connector to avoid damage to the connection.
• Ensure all connectors are clean and dry before connecting the cable.

Safe Use:
• Arrange cables to avoid tripping hazards, especially in areas with pedestrian traffic.
• Prevent cables from being pinched or cut, such as by doors or sharp edges.

Observe Load Limits:
• Do not exceed the load limits of the cable based on its length and quality to prevent signal loss or damage.
• Avoid tensioning the cable, particularly during mobile use.

Protection from Environmental Factors:
• Do not use audio cables in extremely humid, hot, or cold environments unless they are designed for such conditions.
• Store cables in a dry and clean location when not in use.

Compatibility
• Ensure the audio cable is compatible with the equipment in use (e.g., amplifiers, instruments, microphones). Use the recommended connector types (e.g., XLR, TRS, RCA).
• Cables with insufficient shielding can cause interference and signal loss.

Warning Notices
• Tripping and Falling Hazard: Improperly placed cables can be a tripping hazard and cause injury.
• Electric Shock Hazard: Damaged cables, especially those with exposed wires, can cause electric shock.
• Fire Hazard: Do not use damaged cables. Short circuits or overheating may lead to fire.
• Risk from Improper Use: Improper handling can cause damage to connected devices, such as signal interference or overvoltage.

Contact Information
For further information visit the manufacturers homepage our shop support team at:
Tech Creation Lab Leipzig UG (haftungsbeschränkt)
Nonnenstrasse 19, 04229 Leipzig, Germany
support@exploding-shed.com

Please read this safety guide before installation or use.

Intended Use
• This product is a Eurorack power supply module (busboard/distribution board) intended to supply Eurorack-compatible synthesizer modules with ±12V and +5V.
• It must be installed in a suitable Eurorack case by the end customer.
• The power supply works with an external plug-in or desktop power adapter (not always included). Only use a compatible adapter with the specified voltage, current, and polarity.
• Any use outside the intended application may result in malfunction, fire hazard, or electric shock.

Assembly Requirements (for kit versions only)
• If supplied as a kit, the product is intended for adult users experienced in electronics and modular synthesis.
• Assembly, including soldering, is required.
• Ensure a clean, well-lit and ventilated workspace free of flammable materials during assembly.
• Use appropriate tools and safety equipment, such as eye protection.

Testing (for kit versions only)
• Test the module thoroughly for shorts or incorrect assembly before powering it in your Eurorack system.
• Incorrectly assembled modules may damage the entire Eurorack system. Test in a separate case with only the single module whenever possible.
• Use a multimeter or other appropriate tools to confirm proper functionality.

Installation and Use
• Disconnect the external power adapter from mains before installation or maintenance.
• Mount the power supply securely inside the case using suitable screws and spacers to avoid mechanical stress or short circuits.
• Ensure correct polarity and orientation when connecting modules. Incorrect connection may damage modules or the entire system.
• Do not exceed the maximum current ratings for each power rail.
• Ensure sufficient ventilation inside the case to prevent overheating.
• Route cables carefully to avoid kinks, pinching, or contact with sharp edges.
• Only use original or manufacturer-approved external power adapters.

Warnings
• Risk of electric shock: the product operates with voltages supplied from mains-powered adapters. Never touch live contacts.
• Risk of fire: overloading, blocked ventilation, or defective components can cause overheating.
• Risk of damage: incorrect polarity or overvoltage may permanently damage modules or the power supply.
• Short circuit hazard: prevent contacts or busboard rails from touching conductive objects.
• Small parts may pose a choking hazard. Keep away from children and pets.
• Do not open, modify, or repair the product yourself. Improper handling may cause injury or permanent damage.

Storage and Cleaning
• Store the product in a dry, cool place away from moisture and extreme temperatures.
• Disconnect the power adapter before cleaning.
• Clean with a dry cloth only. Do not use water or aggressive cleaning agents.

Responsibility (for kit versions only)
Users are solely responsible for proper assembly and testing. Contact manufacturer support for assistance if needed.

Environmental Safety
• Dispose of the module, its components, and packaging in accordance with local electronic waste regulations.

Liability Disclaimer
• The manufacturer or distributor is not responsible for any injury, damage, or malfunction resulting from improper installation, assembly, use, or modification of this product.

Contact Information
For further information visit the manufacturer’s homepage or contact our shop support team at:
Tech Creation Lab Leipzig UG (haftungsbeschränkt)
Nonnenstrasse 19, 04229 Leipzig, Germany
support@exploding-shed.com
