Midiphy - zetaSID (Assembled)

zetaSID is a compact 4HP Eurorack synthesizer voice that brings the legendary SID sound into a modern modular format. Based on the MIDIbox SID synthesis engine, it offers deep digital sound design, animated OLED visual feedback and powerful expansion through the midiphy phybus system.

A single zetaSID works as a monophonic CV/gate-controlled SID voice, while multiple units can be linked into a larger polyphonic instrument. With nexusMIDI and phybus expansion, zetaSID can grow into a full MIDI-controlled synthesizer with up to six stereo voices, while unused CV and gate inputs can be reassigned as additional modulation sources.

The sound engine includes six LFOs, two advanced envelopes, eight modulation paths, four wave sequencers, three oscillator arpeggiators and a 24 × 14 trigger matrix. This allows everything from classic chiptune tones and animated arpeggios to acid-style basslines, evolving digital textures and percussive C64-inspired sounds. zetaSID also includes Lead, Bassline and Drum engines, giving it a wide range of synthesis options in a very small footprint.

The integrated OLED display visualizes oscillator outputs, arpeggio patterns, filter curves and other sound parameters, making patch editing more immediate. Thanks to phybus UI cooperation, multiple zetaSID modules can work together as one expanded interface, with different units controlling different parts of the same patch.

zetaSID ships with 100 preset patches in its internal ROM bank and supports optional microSD storage for session recall and patch handling. With its milled aluminium front panel, compact depth and strong modular connectivity, zetaSID is a powerful SID-inspired Eurorack voice for chiptune, basslines, drums, experimental synthesis and expandable polyphonic setups.

Features
• Compact 4HP Eurorack SID synthesizer voice.
• Based on the MIDIbox SID synthesis engine.
• Monophonic CV/gate control or expandable polyphonic MIDI setup.
• phybus expansion for multi-unit linking and UI cooperation.
• Up to six stereo voices with 12 linked zetaSID modules.
• Lead, Bassline and Drum sound engines.
• Six LFOs, two envelopes and eight modulation paths.
• Four wave sequencers and three oscillator arpeggiators.
• 24 × 14 event trigger matrix for deep sound design.
• Animated OLED display for oscillator, filter and pattern visualization.
• 100 factory ROM patches included.
• Optional microSD support for saving and recalling sessions.
• CV input, gate input and Eurorack  audio output.
